PLAN 1037-12
Key Specs
5022
sq ft
4
Beds
5.5
Baths
2
Floors
3
Garages
Cost to Build Reports Only $19.99 for a Limited Time!
This report will provide you cost estimates based on location and building materials.
Phone: 1-800-447-0027
See our Terms & Conditions and Privacy Policy.
PLAN 1037-12
This plan can be customized
Tell us about your desired changes so we can prepare an estimate for the design service. Click the button to submit your request for pricing, or call 1-800-447-0027 for assistance.
Full Specs & Features
Height : 23'
Width : 130'
Basement Unfinished: 792 sq/ft height 7' 10"
First Floor: 2907 sq/ft height 9'
Framing : Wood - 2x6
Formal Dining Room
Guest Suite
Walk In Closet
Kitchenette Wet Bar
Exercise Room
Family Room Keeping Room
Main Floor Laundry
Bedroom 2:
188 sq/ft width 13' x depth 14' 6"
Bedroom 3:
241 sq/ft width 12' 10" x depth 18' 10"
Breakfast Nook:
164 sq/ft width 13' 6" x depth 12' 2"
Den:
200 sq/ft width 12' x depth 16' 8"
Dining Room:
162 sq/ft width 14' 2" x depth 11' 6"
Entry:
197 sq/ft width 12' 4" x depth 16'
Exercise Room:
259 sq/ft width 17' 6" x depth 14' 10"
Family Room:
577 sq/ft width 30' 8" x depth 18' 10"
Great Room:
402 sq/ft width 21' 2" x depth 19'
Guest Bedroom:
160 sq/ft width 12' 6" x depth 12' 10"
Kitchen:
352 sq/ft width 22' x depth 16'
Master Bathroom:
208 sq/ft width 13' x depth 16'
Master Bedroom:
306 sq/ft width 17' x depth 18'
Storage:
1479 sq/ft width 51' x depth 29'
Storage:
396 sq/ft width 14' 8" x depth 27'
Utility Room:
84 sq/ft width 12' x depth 7'
What's Included In This Plan Set
All plans are drawn at ¼” scale or larger and include :
- Foundation Plan: Drawn to 1/4" scale, this page shows all necessary notations and dimensions including support columns, walls and excavated and unexcavated areas.
- Exterior Elevations: A blueprint picture of all four sides showing exterior materials and measurements.
- Floor Plan(s): Detailed plans, drawn to 1/4" scale for each level showing room dimensions, wall partitions, windows, etc. as well as the location of electrical outlets and switches.
- Cross Section: A vertical cutaway view of the house from roof to foundation showing details of framing, construction, flooring and roofing.
- Interior Elevations: Detailed drawings of kitchen cabinet elevations and other elements as required.
| PDF Set : $1152.00 |
PDF plan sets are best for fast electronic delivery and inexpensive local printing. |
| 5 Copy Set : $1242.00 |
5 printed plan sets mailed to you. |
| 8 Copy Set : $1332.00 |
8 printed plan sets mailed to you. |
| CAD Set : $2304.00 |
For use by design professionals to make substantial changes to your house plan and inexpensive local printing. |
| Single Set : $1062.00 |
One printed set for bidding purposes only. Not a legal building set for construction. |
Foundation
| Daylight Basement: $0.00 |
Ideal for sloping lot, lower level of home partially underground. |
Framing
| Wood 2x6: $0.00 |
Wood 2x6 |
Additional Options
| Right-Reading Reverse : $180.00 |
Choose this option to reverse your plans and to have the text and dimensions readable. |
| Additional Construction Sets : $54.00 |
Additional hard copies of the plan (can be ordered at the time of purchase and within 90 days of the purchase date). |
| Audio Video Design : $90.00 |
Receive an overlay sheet with suggested placement of audio and video components. |
| Construction Guide : $35.10 |
Educate yourself about basic building ideas with these four detailed diagrams that discuss electrical, plumbing, mechanical, and structural topics. |
| Lighting Design : $180.00 |
Receive an overlay sheet with suggested placement of lighting fixtures. |
*Alternate Foundations may take time to prepare.
*Options with a fee may take time to prepare. Please call to confirm.
