PLAN 542-17

This plan can be customized

Tell us about your desired changes so we can prepare an estimate for the design service. Click the button to submit your request for pricing, or call 1-800-447-0027 for assistance.

Modify This Plan

Plan Description


This modern design floor plan is 2622 sq ft and has 3 bedrooms and 3 bathrooms.

Full Specs & Features


Dimension

Depth : 52'

Height : 27' 7"

Width : 50'

Area

Decks : 2681 sq/ft

Garage : 853 sq/ft

Main Floor : 2681 sq/ft

Porch : 1776 sq/ft

* Total Square Footage typically only includes conditioned space and does not include garages, porches, bonus rooms, or decks.

Ceiling

Ceiling Details : Flat ceiling

Garage Ceiling : 8' 6"

Main Ceiling : 9' 7"

Roof

Roof Framing : Wood and Eco-Friendly Materials

Roof Type : Roof Garden

Exterior Wall Framing

Exterior Wall Finish : Plaster/Stucco

Framing : Wood and Eco-Friendy Materials

Insulation : Rockwool and Wood-Fibre Panels

Bedroom Features

Main Floor Bedrooms

Main Floor Master Bedroom

Walk In Closet

Kitchen Features

Kitchen Island

Additional Room Features

Great Room Living Room

Loft

Main Floor Laundry

Wine Cellar

Garage Features

Front Entry Garage

Entryway

Friend S Entry

Lot Characteristics

Suited For Corner Lot

Suited For View Lot

Zero Lot Lines

Outdoor Spaces

Balcony

Breezeway

Covered Front Porch

Wrap Around Porch

More

Wheelchair Adaptable

Energy Efficient Features

Energy Efficient Design

What's Included In This Plan Set


All plans are drawn at ¼” scale or larger and include :

  • Foundation Plan: Drawn to 1/4" scale, this page shows all necessary notations and dimensions including support columns, walls and excavated and unexcavated areas.
  • Exterior Elevations: A blueprint picture of all four sides showing exterior materials and measurements.
  • Floor Plan(s): Detailed plans, drawn to 1/4" scale for each level showing room dimensions, wall partitions, windows, etc. as well as the location of electrical outlets and switches.
  • Cross Section: A vertical cutaway view of the house from roof to foundation showing details of framing, construction, flooring and roofing.
  • Interior Elevations: Detailed drawings of kitchen cabinet elevations and other elements as required.
» See important information before purchasing.
