PLAN 70-557
Key Specs
5752
sq ft
4
Beds
4.5
Baths
2
Floors
3
Garages
Cost to Build Reports Only $9.99 with Code CTB2021 (Limit 1 Per Order)
This report will provide you cost estimates based on location and building materials.
Phone: 1-800-447-0027
See our Terms & Conditions and Privacy Policy.
PLAN 70-557
This plan can be customized
Tell us about your desired changes so we can prepare an estimate for the design service. Click the button to submit your request for pricing, or call 1-800-447-0027 for assistance.
Full Specs & Features
Height : 35'
Width : 121'
Second Floor: 1784 sq/ft
Roof Framing : Truss
Roof Type : Shingle
Secondary Pitch : 10:12
Framing : 2"x6"
Walk In Closet
Kitchen Island
Walk In Pantry Cabinet Pantry
Family Room Keeping Room
Hobby Rec Room Game Room
Loft
Storage Area
Sunroom
Unfinished Future Space
Side Entry Garage
Suited For Sloping Lot
Suited For View Lot
Screened Porch
Bedroom 2:
180 sq/ft width 15' x depth 12'
Bedroom 2 Closet:
36 sq/ft width 4' 6" x depth 8'
Bedroom 3:
316 sq/ft width 19' x depth 16' 8"
Bedroom 3 Closet:
36 sq/ft width 4' 6" x depth 8'
Bedroom 4:
224 sq/ft width 15' 4" x depth 14' 8"
Bedroom 4 Closet:
38 sq/ft width 5' 6" x depth 7'
Breakfast Room:
244 sq/ft width 13' 10" x depth 17' 8"
Dining Room:
210 sq/ft width 15' x depth 14'
Family Room:
399 sq/ft width 19' x depth 21'
Garage:
635 sq/ft width 29' 4" x depth 21' 8"
Garage Two:
679 sq/ft width 28' 4" x depth 24'
Kitchen:
502 sq/ft width 26' x depth 19' 4"
Laundry Room:
40 sq/ft width 5' 4" x depth 7' 8"
Living Room:
391 sq/ft width 21' 4" x depth 18' 4"
Loft:
214 sq/ft width 15' 4" x depth 14'
Master Bathroom:
297 sq/ft width 19' x depth 15' 8"
Master Bedroom:
470 sq/ft width 23' 6" x depth 20'
Master Closet:
86 sq/ft width 7' 2" x depth 12'
Master Closet Two:
86 sq/ft width 7' 2" x depth 12'
Office:
88 sq/ft width 14' 8" x depth 6'
Pantry:
53 sq/ft width 8' x depth 6' 8"
Porch - Screened:
224 sq/ft width 11' 6" x depth 19' 6"
Powder Room:
41 sq/ft width 7' 4" x depth 5' 8"
Study:
270 sq/ft width 15' x depth 18'
