PLAN 70-740

This plan can be customized

Tell us about your desired changes so we can prepare an estimate for the design service. Click the button to submit your request for pricing, or call 1-800-447-0027 for assistance.

Modify This Plan

Plan Description


This traditional design floor plan is 5786 sq ft and has 3 bedrooms and 3 bathrooms.

Full Specs & Features


Dimension

Depth : 67'

Height : 25'

Width : 93' 4"

Area

Basement Living: 1216 sq/ft

Basement Living: 888 sq/ft

First Floor: 2027 sq/ft

First Floor: 1655 sq/ft

* Total Square Footage typically only includes conditioned space and does not include garages, porches, bonus rooms, or decks.

Ceiling

Main Ceiling : 9'

Roof

Primary Pitch : 7:12

Roof Framing : Truss

Roof Type : Shingle

Exterior Wall Framing

Exterior Wall Finish : Brick/Stucco

Framing : 2"x6"

Bedroom Features

Split Bedrooms

Kitchen Features

Breakfast Nook

Additional Room Features

Family Room Keeping Room

Storage Area

Sunroom

Outdoor Spaces

Screened Porch

Rooms

Bedroom 2:

153 sq/ft width 13' x depth 11' 10"

Bedroom 2:

153 sq/ft width 14' 2" x depth 10' 10"

Bedroom 3:

219 sq/ft width 15' 10" x depth 13' 10"

Bedroom 3:

166 sq/ft width 14' 8" x depth 11' 4"

Dining Room:

178 sq/ft width 14' 8" x depth 12' 2"

Dining Room:

133 sq/ft width 10' x depth 13' 4"

Family Room:

696 sq/ft width 31' 2" x depth 22' 4"

Family Room:

619 sq/ft width 23' 10" x depth 26'

Garage:

462 sq/ft width 21' 4" x depth 21' 8"

Garage:

483 sq/ft width 22' 4" x depth 21' 8"

Kitchen:

212 sq/ft width 14' 4" x depth 14' 10"

Kitchen:

97 sq/ft width 9' 2" x depth 10' 8"

Library:

147 sq/ft width 12' 4" x depth 12'

Living Room:

379 sq/ft width 17' x depth 22' 4"

Living Room:

311 sq/ft width 19' 8" x depth 15' 10"

Master Bedroom:

224 sq/ft width 15' 6" x depth 14' 6"

Master Bedroom:

247 sq/ft width 14' x depth 17' 8"

Nook:

75 sq/ft width 7' 6" x depth 10'

Nook:

80 sq/ft width 7' 6" x depth 10' 8"

Porch - Screened:

145 sq/ft width 15' x depth 9' 8"

Porch - Screened:

137 sq/ft width 12' 6" x depth 11'

What's Included In This Plan Set


  • Cover sheet with front rendering
  • Foundation and floor plans at 1/4" = 1' scale
  • Exterior elevations of all four views, front at 1/4" = 1' scale, rear and sides vary from 1/8" to 1/4" = 1' scale
  • Building sections and details as required to construct the individual design
  • Interior elevation of cabinets at 1/4" = 1' scale
  • Roof plans
  • Schematic electrical plans with suggested switch, outlet, and light fixture locations General specification design notes
  • Note: Mechanical and plumbing drawings are not included. These should be obtained from a local mechanical contractor to ensure correct sizing of equipment for your region and climate conditions.
  • Please note, if you are building in the state of Wisconsin, please give us a call before placing your order.
» See important information before purchasing.
Questions? Call 1-800-447-0027

Plan Set

5 Copy Set:
$3761.00
5 printed plan sets mailed to you.
8 Copy Set:
$3993.00
8 printed plan sets mailed to you.
PDF Set:
$5497.00
PDF plan sets are best for fast electronic delivery and inexpensive local printing.
Reproducible Set:
$5497.00
For inexpensive local printing / making minor adjustments by hand. 1 printed set, typically on Bond paper.
CAD Set:
$10705.00
For use by design professionals to make substantial changes to your house plan and inexpensive local printing.

Foundation

Walk Out Basement:
$0.00
Ideal for a sloping lot, lower level with outdoor access.
Crawlspace:
$650.00
Ideal for semi-sloped or level lot, home can be built off of grade, typically 18” - 48”.
Slab:
$650.00
Ideal for level lot, single layer concrete poured directly on grade.

Additional Options

Right-Reading Reverse:
$395.00
Choose this option to reverse your plans and to have the text and dimensions readable.
Additional Construction Sets:
$80.00
Additional hard copies of the plan (can be ordered at the time of purchase and within 90 days of the purchase date).
Audio Video Design:
$100.00
Receive an overlay sheet with suggested placement of audio and video components.
Comprehensive Material List:
$495.00
A complete list of building supplies needed to construct the infrastructure of your new house, plus an overlay of materials shown directly on your PDF (foundation to rooftop with interior and exterior materials), and a detailed, itemized door and window schedule showing all sizes and types. Please allow 5-7 Business Days for completion. Note, the Comprehensive list is only available with a PDF purchase. The Comprehensive list can be ordered no matter what additional plan options you have selected.
Construction Guide:
$39.00
Educate yourself about basic building ideas with these four detailed diagrams that discuss electrical, plumbing, mechanical, and structural topics.
Mirror Reversed Sets:
$75.00
A mirror-reversed set is a printed copy of your house, resulting in the same image you would see if you held the drawing up to a mirror. Everything, including the text, is backward in relation to the original design. These kinds of drawing are typically used to reorient an original plan more advantageously on a site, either because the homeowner prefers it that way or because of limitations of the site itself. Note: Mirror reverse sets are only available with a 5 copy or 8 copy set. With a Reproducible, PDF, or CAD set, you can print mirrored copies locally. In addition: 5 Copy set selected, should only allow 4 mirrored sets to be selected. 8 Copy set selected, should only allow 7 mirrored sets to be selected.

* Alternate Foundations may take time to prepare.

** Options with a fee may take time to prepare. Please call to confirm.

Unless you buy an “unlimited” plan set or a multi-use license you may only build one home from a set of plans. Please call to verify if you intend to build more than once. Plan licenses are non-transferable and cannot be resold.
