This four-plex combines straight-forward, cost-effective construction with high curb appeal. Front and rear porches, exterior storage and individual garages help attract buyers. Nine foot ceilings, large sunny windows, and a functional, open and efficient floor plan add even more value. The 2nd floor has three well proportioned bedrooms including a large master with a walk-in closet. The larger end unit is ADA (handicapped) compliant and comes with big bay windows and a huge master bedroom. These plans come complete with comprehensive green specifications, meeting the EPA's Energy Stars "Designed to Earn" program.

Full Specs & Features


Dimension

Depth : 49'

Height : 34'

Width : 121'

Area

First Floor: 660 sq/ft

First Floor: 630 sq/ft

First Floor: 630 sq/ft

First Floor: 910 sq/ft

Second Floor: 870 sq/ft

Third Floor: 870 sq/ft

Third Floor: 870 sq/ft

Third Floor: 1090 sq/ft

* Total Square Footage typically only includes conditioned space and does not include garages, porches, bonus rooms, or decks.

Roof

Primary Pitch : 9:12

Roof Framing : Combination Truss/Conventional

Roof Type : Composition

Secondary Pitch : 10:12

Exterior Wall Framing

Exterior Wall Finish : Siding

Framing : Wood - 2x6

Bedroom Features

Formal Dining Room

Formal Living Room / Parlor

Guest Suite

Main Floor Master Bedroom

Walk In Closet

Kitchen Features

Kitchen Island

Additional Room Features

Main Floor Laundry

Outdoor Spaces

Covered Front Porch

Covered Rear Porch

Deck

Rooms

Bedroom 1:

174 sq/ft width 12' x depth 14' 6"

Bedroom 2:

143 sq/ft width 11' x depth 13'

Bedroom 2:

143 sq/ft width 11' x depth 13'

Bedroom 2:

143 sq/ft width 11' x depth 13'

Bedroom 2:

156 sq/ft width 13' x depth 12'

Bedroom 3:

120 sq/ft width 10' x depth 12'

Bedroom 3:

120 sq/ft width 10' x depth 12'

Bedroom 3:

120 sq/ft width 10' x depth 12'

Bedroom 3:

174 sq/ft width 12' x depth 14' 6"

Dining Room:

94 sq/ft width 8' x depth 11' 9"

Dining Room:

94 sq/ft width 8' x depth 11' 9"

Dining Room:

94 sq/ft width 8' x depth 11' 9"

Dining Room:

94 sq/ft width 8' x depth 11' 9"

Garage:

253 sq/ft width 11' 6" x depth 22'

Garage:

253 sq/ft width 11' 6" x depth 22'

Garage:

253 sq/ft width 11' 6" x depth 22'

Garage:

253 sq/ft width 11' 6" x depth 22'

Kitchen:

181 sq/ft width 12' 6" x depth 14' 6"

Kitchen:

181 sq/ft width 12' 6" x depth 14' 6"

Kitchen:

181 sq/ft width 12' 6" x depth 14' 6"

Kitchen:

168 sq/ft width 16' x depth 10' 6"

Living Room:

182 sq/ft width 13' 3" x depth 13' 9"

Living Room:

182 sq/ft width 13' 3" x depth 13' 9"

Living Room:

182 sq/ft width 13' 3" x depth 13' 9"

Living Room:

217 sq/ft width 15' x depth 14' 6"

Master Bedroom:

182 sq/ft width 13' 3" x depth 13' 9"

Master Bedroom:

182 sq/ft width 13' 3" x depth 13' 9"

Master Bedroom:

182 sq/ft width 13' 3" x depth 13' 9"

Master Bedroom:

217 sq/ft width 15' x depth 14' 6"
