PLAN 40-236

Home > Style > Traditional House Plans

Key Specs

1659
sq ft

3
Beds

2
Baths

1
Floors

2
Garages

This plan can be customized

Tell us about your desired changes so we can prepare an estimate for the design service. Click the button to submit your request for pricing, or call 1-800-447-0027 for assistance.

Modify This Plan

Plan Description

This traditional design floor plan is 1659 sq ft and has 3 bedrooms and 2 bathrooms.

Floor Plans

Floor Plan - Main Floor

Reverse

BUILDER Advantage Program

Pro Builders:

Join the club and save 5% on your first home plan order. PLUS download our exclusive house plans trend report!

Join for FREE

Click to Get Your Trend Report

Floor Plan - Other Floor

Reverse

Full Specs & Features

Dimension

Depth : 46'

Height : 27'

Width : 55' 6"

Area

Bonus: 250 sq/ft

First Floor: 1659 sq/ft height 8'

* Total Square Footage typically only includes conditioned space and does not include garages, porches, bonus rooms, or decks.

Ceiling

Main Ceiling : 8'

Roof

Primary Pitch : 10:12

Roof Framing : Conventional

Roof Type : Tile

Exterior Wall Framing

Exterior Wall Finish : Brick/Siding

Framing : 2"x4"

Bedroom Features

Split Bedrooms

Walk In Closet

Kitchen Features

Eating Bar

Additional Room Features

Great Room Living Room

Master Sitting Area

Outdoor Spaces

Covered Front Porch

Covered Rear Porch

Rooms

Bathroom 2:

55 sq/ft width 11' x depth 5'

Bedroom 2:

110 sq/ft width 10' x depth 11'

Bedroom 3:

100 sq/ft width 10' x depth 10'

Bonus Room - Finished:

220 sq/ft width 10' x depth 22'

Covered Front Porch:

width 21' 8" x depth 5'

Covered Rear Porch:

width 10' 11" x depth 21' 2"

Dining Room:

121 sq/ft width 11' x depth 11'

Entry:

56 sq/ft width 5' 3" x depth 10' 8"

Garage:

473 sq/ft width 21' 6" x depth 22'

Kitchen:

121 sq/ft width 11' x depth 11'

Living Room:

300 sq/ft width 20' x depth 15'

Master Bedroom:

180 sq/ft width 15' x depth 12'

Master Closet:

26 sq/ft width 4' 5" x depth 6'

Master Closet Two:

41 sq/ft width 6' 7" x depth 6' 3"

Utility Room:

43 sq/ft width 5' 6" x depth 7' 11"

What's Included In This Plan Set

See a sample plan set

All plans are drawn at ¼” scale or larger and include :

Foundation Plan: This page shows all necessary notations and dimensions including support columns, walls, and excavated/unexcavated areas.
Exterior Elevations: Views of the home from all four sides showing exterior materials and measurements.
Floor Plan(s): Detailed plans for each level showing room dimensions, wall partitions, windows and doors, etc.
Cross Section: A slice of the home from roof to foundation, showing important details like stairs and wall construction.
Overhead Roof Plan(s): A view of the home from above showing roof pitch, peaks, valleys, and other details.
Construction Notes and Details: Shows the builder how things come together, like walls, the chimney, insulation, and more.

Questions? Call 1-800-447-0027

Plan Set

5 Copy Set:
$675.00

5 printed plan sets mailed to you.

8 Copy Set:
$765.00

8 printed plan sets mailed to you.

PDF Set:
$850.00

PDF plan sets are best for fast electronic delivery and inexpensive local printing.

Reproducible Set:
$850.00

For inexpensive local printing / making minor adjustments by hand. 1 printed set, typically on Bond paper.

CAD Set:
$1425.00

For use by design professionals to make substantial changes to your house plan and inexpensive local printing.

Single Set:
$575.00

One printed set for bidding purposes only. Not a legal building set for construction.

Foundation

Crawlspace:
$0.00

Ideal for semi-sloped or level lot, home can be built off of grade, typically 18” - 48”.

Slab:
$0.00

Ideal for level lot, single layer concrete poured directly on grade.

Additional Options

Right-Reading Reverse:
$100.00

Choose this option to reverse your plans and to have the text and dimensions readable.

Additional Construction Sets:
$50.00

Additional hard copies of the plan (can be ordered at the time of purchase and within 90 days of the purchase date).

Audio Video Design:
$100.00

Receive an overlay sheet with suggested placement of audio and video components.

Construction Guide:
$39.00

Educate yourself about basic building ideas with these four detailed diagrams that discuss electrical, plumbing, mechanical, and structural topics.

Lighting Design:
$100.00

Receive an overlay sheet with suggested placement of lighting fixtures.

Mirror Reversed Sets:
$50.00

A mirror-reversed set is a printed copy of your house, resulting in the same image you would see if you held the drawing up to a mirror. Everything, including the text, is backward in relation to the original design. These kinds of drawing are typically used to reorient an original plan more advantageously on a site, either because the homeowner prefers it that way or because of limitations of the site itself. Note: Mirror reverse sets are only available with a 5 copy or 8 copy set. With a Reproducible, PDF, or CAD set, you can print mirrored copies locally. In addition: 5 Copy set selected, should only allow 4 mirrored sets to be selected. 8 Copy set selected, should only allow 7 mirrored sets to be selected.

* Alternate Foundations may take time to prepare.

** Options with a fee may take time to prepare. Please call to confirm.

Unless you buy an “unlimited” plan set or a multi-use license you may only build one home from a set of plans. Please call to verify if you intend to build more than once. Plan licenses are non-transferable and cannot be resold.
