Key Specs
1882
sq ft
3
Beds
2.5
Baths
1
Floors
3
Garages
Phone: 1-800-447-0027
See our Terms & Conditions and Privacy Policy.
Use Code CTBBF (limit 1)
Residential Construction Guide
Learn Building Basics
This downloadable, 26-page guide is full of diagrams and details about plumbing, electrical, and more.
PLAN 70-644
This plan can be customized
Tell us about your desired changes so we can prepare an estimate for the design service. Click the button to submit your request for pricing, or call 1-800-447-0027 for assistance.
Plan Description
Floor Plans
Full Specs & Features
Dimension
Depth : 72'
Height : 26'
Width : 42' 8"
Area
First Floor: 1882 sq/ft
Roof
Primary Pitch : 10:12
Roof Framing : Truss
Roof Type : Shingle
Exterior Wall Framing
Exterior Wall Finish : Siding/Stone
Framing : 2"x6"
Bedroom Features
Walk In Closet
Kitchen Features
Kitchen Island
Garage Features
Oversized Garage
Tandem Garage
Lot Characteristics
Suited For Corner Lot
Suited For View Lot
Outdoor Spaces
Covered Front Porch
Rooms
3rd BR Closet:
10 sq/ft width 5' 2" x depth 2'
Basement Foundation:
3096 sq/ft width 72' x depth 43'
Bedroom 2:
147 sq/ft width 13' x depth 11' 4"
Bedroom 2 Closet:
13 sq/ft width 6' 8" x depth 2'
Bedroom 3:
156 sq/ft width 12' 8" x depth 12' 4"
Bedroom 3 Closet:
13 sq/ft width 6' 8" x depth 2'
Dining Room:
167 sq/ft width 11' 8" x depth 14' 4"
Foyer:
26 sq/ft width 7' 8" x depth 3' 6"
Garage:
878 sq/ft width 23' 4" x depth 37' 8"
Hall:
43 sq/ft width 13' 2" x depth 3' 4"
Hall Bathroom:
41 sq/ft width 8' 4" x depth 5'
Hall Closet:
6 sq/ft width 3' x depth 2'
Kitchen:
138 sq/ft width 10' 8" x depth 13'
Laundry Room:
83 sq/ft width 8' 8" x depth 9' 8"
Living Room:
365 sq/ft width 20' 8" x depth 17' 8"
Master Bathroom:
113 sq/ft width 12' 2" x depth 9' 4"
Master Bedroom:
227 sq/ft width 13' 6" x depth 16' 10"
Master Closet:
49 sq/ft width 8' 4" x depth 6'
Powder Room:
26 sq/ft width 8' 8" x depth 3'
Slab Foundation:
924 sq/ft width 24' 4" x depth 38'
