PLAN 120-184
This plan can be customized
Tell us about your desired changes so we can prepare an estimate for the design service. Click the button to submit your request for pricing, or call 1-800-447-0027 for assistance.Plan Description
Rugged yet elegant, the exterior of this house design will draw all eyes. Inside, a two-sided fireplace creates drama (the good kind) in both the dining room and the family room, with the latter flowing into the island kitchen. The master suite steps out to the lanai. One of the three additional bedrooms includes a private bath, making it a great place for guests or an in-law. Don't miss the spacious bonus room upstairs.
Full Specs & Features
Dimension
Depth : 86' 6"
Height : 29' 4"
Width : 81' 6"
Height : 29' 4"
Width : 81' 6"
Area
Bonus: 473 sq/ft
First Floor: 2482 sq/ft height 9'
Garage: 695 sq/ft
First Floor: 2482 sq/ft height 9'
Garage: 695 sq/ft
*Total Square Footage only includes conditioned space and does not include garages, porches, bonus rooms, or decks.
Ceiling
Bonus Ceiling : 9'
Ceiling Details : Vaults at Family, Dining and Master
Garage Ceiling : 8'
Main Ceiling : 10'
Ceiling Details : Vaults at Family, Dining and Master
Garage Ceiling : 8'
Main Ceiling : 10'
Roof
Primary Pitch : 12:12
Roof Framing : stick
Roof Load : 40
Roof Type : Composition
Secondary Pitch : 14:12
Roof Framing : stick
Roof Load : 40
Roof Type : Composition
Secondary Pitch : 14:12
Exterior Wall Framing
Exterior Wall Finish : stone/shake
Framing : 2x4
Insulation : R-15
Framing : 2x4
Insulation : R-15
Bedroom Features
Main Floor Bedrooms
Main Floor Master Bedroom
Split Bedrooms
Walk In Closet
Main Floor Master Bedroom
Split Bedrooms
Walk In Closet
Kitchen Features
Breakfast Nook
Eating Bar
Kitchen Island
Walk In Pantry Cabinet Pantry
Eating Bar
Kitchen Island
Walk In Pantry Cabinet Pantry
Additional Room Features
Den Office Study Computer
Main Floor Laundry
Play Flex Room
Unfinished Future Space
Main Floor Laundry
Play Flex Room
Unfinished Future Space
Outdoor Spaces
Covered Front Porch
Covered Rear Porch
Grill Deck Sundeck
Outdoor Kitchen Grill
Covered Rear Porch
Grill Deck Sundeck
Outdoor Kitchen Grill
More
Jack & Jill Bath
Unusual Shape
Unusual Shape
Rooms
Bedroom 2:
width 13' 8" x depth 12'
Bedroom 3:
width 13' 8" x depth 11'
Bedroom 4:
width 12' x depth 12'
Bonus:
473 sq/ft width 26' x depth 14' 2"
Dining:
width 11' x depth 14'
Garage:
695 sq/ft width 26' x depth 24' 4"
Kitchen:
width 10' x depth 15'
Lanai:
305 sq/ft width 19' x depth 16'
Master Bath:
width 12' x depth 9'
Master Bedroom:
width 14' x depth 16'
Nook:
width 10' x depth 11'
Pantry:
width 3' 8" x depth 3' 8"
Porch Front:
196 sq/ft width 22' x depth 8'
Study:
width 11' 6" x depth 12'
Trellis Area:
width 9' x depth 18'
