PLAN 72-175
Cost to Build Reports Only $19.99 for a Limited Time!
This report will provide you cost estimates based on location and building materials.
Phone: 1-800-447-0027
See our Terms & Conditions and Privacy Policy.
PLAN 72-175
This plan can be customized
Tell us about your desired changes so we can prepare an estimate for the design service. Click the button to submit your request for pricing, or call 1-800-447-0027 for assistance.
Full Specs & Features
Height : 21'
Width : 77' 6"
Second Floor: 714 sq/ft
Roof Type : Build-Up
Framing : Wood - 2x6
Main Floor Master Bedroom
Walk In Closet
Suited For View Lot
3rd BR Closet:
31 sq/ft width 6' x depth 5' 2"
Bathroom 2:
38 sq/ft width 5' 1" x depth 7' 6"
Bathroom 3:
67 sq/ft width 6' x depth 11' 4"
Bedroom 2:
182 sq/ft width 13' x depth 14'
Bedroom 2 Closet:
42 sq/ft width 5' x depth 8' 6"
Bedroom 3:
182 sq/ft width 13' x depth 14'
Bedroom 3 Closet:
42 sq/ft width 5' x depth 8' 6"
Bedroom 4 Closet:
31 sq/ft width 6' 2" x depth 5' 2"
Breakfast Room:
64 sq/ft width 8' x depth 8'
Dining Room:
168 sq/ft width 12' x depth 14'
Foyer:
161 sq/ft width 17' x depth 9' 6"
Garage:
506 sq/ft width 23' x depth 22'
Gathering Room:
256 sq/ft width 16' x depth 16'
Hall Closet:
12 sq/ft width 3' 8" x depth 3' 6"
Kitchen:
169 sq/ft width 13' x depth 13'
Laundry Room:
45 sq/ft width 5' 1" x depth 9'
Master Bathroom:
193 sq/ft width 15' 6" x depth 12' 6"
Master Bedroom:
320 sq/ft width 16' x depth 20'
Master Closet:
92 sq/ft width 10' 4" x depth 9'
Porch - Front:
76 sq/ft width 8' x depth 9' 6"
Study:
168 sq/ft width 12' 6" x depth 13' 6"
Wash Room:
28 sq/ft width 5' x depth 5' 8"
What's Included In This Plan Set
All plans are drawn at ¼” scale or larger and include :
- Foundation Plan: Drawn to 1/4" scale, this page shows all necessary notations and dimensions including support columns, walls and excavated and unexcavated areas.
- Exterior Elevations: A blueprint picture of all four sides showing exterior materials and measurements.
- Floor Plan(s): Detailed plans, drawn to 1/4" scale for each level showing room dimensions, wall partitions, windows, etc. as well as the location of electrical outlets and switches.
- Cross Section: A vertical cutaway view of the house from roof to foundation showing details of framing, construction, flooring and roofing.
- Interior Elevations: Detailed drawings of kitchen cabinet elevations and other elements as required.
| PDF Set : $1018.71 |
PDF plan sets are best for fast electronic delivery and inexpensive local printing. |
| 5 Copy Set : $1122.66 |
5 printed plan sets mailed to you. |
| 8 Copy Set : $1226.61 |
8 printed plan sets mailed to you. |
| Reproducible Set : $1226.61 |
For inexpensive local printing / making minor adjustments by hand. 1 printed set, typically on Bond paper. |
| CAD Set : $2037.42 |
For use by design professionals to make substantial changes to your house plan and inexpensive local printing. |
| Single Set : $914.76 |
One printed set for bidding purposes only. Not a legal building set for construction. |
Foundation
| Slab: $0.00 |
Ideal for level lot, single layer concrete poured directly on grade. |
| Basement: $247.50 |
Ideal for level lot, lower level of home partially or fully underground. |
Additional Options
| Additional Construction Sets : $54.00 |
Additional hard copies of the plan (can be ordered at the time of purchase and within 90 days of the purchase date). |
| Additional Use License : $463.50 |
Additional Use License. |
| Audio Video Design : $90.00 |
Receive an overlay sheet with suggested placement of audio and video components. |
| Construction Guide : $35.10 |
Educate yourself about basic building ideas with these four detailed diagrams that discuss electrical, plumbing, mechanical, and structural topics. |
| Material List : $76.50 |
A list of building supplies needed to construct the infrastructure of your new house. Please note materials lists will not reflect add-ons such as alternate foundation and framing options. |
| Mirror Reversed Sets : $54.00 |
A mirror-reversed set is a printed copy of your house, resulting in the same image you would see if you held the drawing up to a mirror. Everything, including the text, is backward in relation to the original design. These kinds of drawing are typically used to reorient an original plan more advantageously on a site, either because the homeowner prefers it that way or because of limitations of the site itself. Note: Mirror reverse sets are only available with a 5 copy or 8 copy set. With a Reproducible, PDF, or CAD set, you can print mirrored copies locally. In addition: 5 Copy set selected, should only allow 4 mirrored sets to be selected. 8 Copy set selected, should only allow 7 mirrored sets to be selected. |
| Unlimited Use License : $926.10 |
Unlimited Use License. |
*Alternate Foundations may take time to prepare.
