PLAN 314-277
This plan can be customized
Tell us about your desired changes so we can prepare an estimate for the design service. Click the button to submit your request for pricing, or call 1-800-447-0027 for assistance.
Plan Description
Floor Plans
Full Specs & Features
Dimension
Depth : 55' 6"
Height : 28'
Width : 72' 8"
Area
First Floor: 2146 sq/ft height 9'
Garage: 624 sq/ft
Porch: 335 sq/ft
Second Floor: 1132 sq/ft height 9'
Roof
Primary Pitch : 12:12
Roof Framing : Conventional
Roof Type : Asphalt
Secondary Pitch : 8:12
Exterior Wall Framing
Exterior Wall Finish : Brick/Shingle
Framing : Wood - 2x4
Bedroom Features
Fireplace
Formal Dining Room
Formal Living Room / Parlor
Guest Suite
Main Floor Master Bedroom
Split Bedrooms
Walk In Closet
Kitchen Features
Breakfast Nook
Butler's Pantry
Kitchen Island
Additional Room Features
Den Office Study Computer
Great Room Living Room
Loft
Main Floor Laundry
Open Floor Plan
Vaulted / Cathedral Ceilings
Garage Features
Side Entry Garage
Outdoor Spaces
Balcony
Covered Front Porch
Rooms
Bedroom 2:
width 15' x depth 13' 4"
Bedroom 3:
width 15' x depth 13'
Dining Room:
width 15' x depth 12' 8"
Garage:
624 sq/ft width 20' x depth 30'
Great Room:
width 19' x depth 18' 4"
Kitchen:
width 19' x depth 15' 4"
Living/Guest Room:
width 12' x depth 15'
Loft:
width 12' 4" x depth 9' 8"
Master Bedroom:
width 13' x depth 17' 8"
Office/Flex Room:
width 19' x depth 16'
Porch - Front:
335 sq/ft
What's Included In This Plan Set
All plans are drawn at ¼” scale or larger and include :
- Foundation Plan: Drawn to 1/4" scale, this page shows all necessary notations and dimensions including support columns, walls and excavated and unexcavated areas.
- Exterior Elevations: A blueprint picture of all four sides showing exterior materials and measurements.
- Floor Plan(s): Detailed plans, drawn to 1/4" scale for each level showing room dimensions, wall partitions, windows, etc. as well as the location of electrical outlets and switches.
- Cross Section: A vertical cutaway view of the house from roof to foundation showing details of framing, construction, flooring and roofing.
- Interior Elevations: Detailed drawings of kitchen cabinet elevations and other elements as required.
Plan Set
$1024.00
$1112.00
$1176.00
$1184.00
$1836.00
Foundation
$0.00
$0.00
$120.00
Framing
$0.00
$120.00
Additional Options
$280.00
$40.00
$80.00
$31.20
$76.00
$40.00
* Alternate Foundations may take time to prepare.
** Options with a fee may take time to prepare. Please call to confirm.
