Key Specs


Plan Sq Ft

4164
sq ft

Plan Bedrooms

4
Beds

Plan Bathrooms

4
Baths

Plan Floors

2
Floors

Plan Garages

3
Garages

Select Plan Set Options

What's included?

Additional options

Dropdown arrow

Right-Reading Reverse
$195.00
Choose this option to reverse your plans and to have the text and dimensions readable.
Additional Construction Sets
$50.00/each
Additional hard copies of the plan (can be ordered at the time of purchase and within 90 days of the purchase date).
Additional Use License
$395.00
Allows you to build one more home for each additional license purchased.
Audio Video Design
$100.00
Receive an overlay sheet with suggested placement of audio and video components.
Comprehensive Material List
$450.00
A complete list of building supplies needed to construct the infrastructure of your new house, plus an overlay of materials shown directly on your PDF (foundation to rooftop with interior and exterior materials), and a detailed, itemized door and window schedule showing all sizes and types. Please allow 5-7 Business Days for completion. Note, the Comprehensive list is only available with a PDF purchase. The Comprehensive list can be ordered no matter what additional plan options you have selected.
Construction Guide
$39.00
Educate yourself about basic building ideas with these four detailed diagrams that discuss electrical, plumbing, mechanical, and structural topics.
Unlimited Use License
$395.00
Allows you to build this home as many times as you want.
3 Car Garage
$195.00
Adds an additional garage bay
Subtotal
$1595.00
Best Price Guaranteed*

Also order by phone: 1-800-447-0027
Cost-to-Build Estimates

How much will this cost to build?

This report will provide you cost estimates based on location and building materials.

Get Cost-To-Build Report
Or order by phone: 1-800-447-0027
Questions about building your home?
Get Personalized Help
We do our best to get back to you within 24 - 48 business hours.
Need an answer faster? Call now...
Phone: 1-800-447-0027
Hours: Mon - Fri 8:30 - 8:30 (EDT)

See our Terms & Conditions and Privacy Policy.

PLAN 120-186

This plan can be customized

Tell us about your desired changes so we can prepare an estimate for the design service. Click the button to submit your request for pricing, or call 1-800-447-0027 for assistance.

Modify This Plan

Full Specs & Features


Dimension

Depth : 98' 11"

Height : 29' 10"

Width : 92' 5"

Area

First Floor: 3390 sq/ft

Garage: 1078 sq/ft

Second Floor: 774 sq/ft

* Total Square Footage typically only includes conditioned space and does not include garages, porches, bonus rooms, or decks.

Ceiling

Main Ceiling : 10'

Upper Ceiling Ft : 9'

Roof

Primary Pitch : 12:12

Roof Framing : Stick

Roof Load : 20 lbs

Roof Type : Metal

Secondary Pitch : 4:12

Exterior Wall Framing

Exterior Wall Finish : Siding/Stone

Framing : 2x4

Insulation : R-13

Bedroom Features

Main Floor Bedrooms

Main Floor Master Bedroom

Split Bedrooms

Walk In Closet

Kitchen Features

Kitchen Island

Walk In Pantry Cabinet Pantry

Additional Room Features

Family Room Keeping Room

Hobby Rec Room Game Room

Main Floor Laundry

Mud Room

Play Flex Room

Storage Area

Garage Features

Side Entry Garage

Lot Characteristics

Suited For View Lot

Outdoor Spaces

Breezeway

Covered Front Porch

Covered Rear Porch

Rooms

Bedroom 3:

width 14' x depth 13'

Bedroom 3 Closet:

width 5' 8" x depth 6'

Bedroom 4:

width 13' x depth 14'

Bedroom 4 Closet:

width 6' 8" x depth 5' 3"

Breezeway:

174 sq/ft

Carport:

523 sq/ft width 22' 5" x depth 23' 4"

Covered Rear Porch:

633 sq/ft width 42' 6" x depth 15' 4"

Dining Area:

width 14' 6" x depth 17' 8"

Family Room:

width 20' 2" x depth 21' 8"

Foyer:

width 8' x depth 8' 6"

Game Room:

width 23' x depth 19' 10"

Garage:

1078 sq/ft width 25' 5" x depth 34' 9"

Garage Storage:

width 6' 8" x depth 16' 2"

Guest Porch:

54 sq/ft

Guest Room:

width 13' 6" x depth 13'

Kitchen:

width 11' 3" x depth 22'

Master Closet:

width 13' 4" x depth 16' 4"

Master Bath:

width 12' x depth 19'

Master Suite:

width 17' 10" x depth 20' 8"

Media Room:

width 18' 10" x depth 13' 4"

Pantry:

width 13' 2" x depth 5'

Utility Room:

width 12' 6" x depth 9'
