PLAN 72-829

This plan can be customized

Tell us about your desired changes so we can prepare an estimate for the design service. Click the button to submit your request for pricing, or call 1-800-447-0027 for assistance.

Modify This Plan

Plan Description


Masterful use of space with a profusion of windows and terrace access are all employed in this Tudor treasure. The living room features a raised-hearth fireplace, a huge bay window and a curved bar. The angular kitchen is strategically placed to serve the formal dining room, the family room with its gracious fireplace and a captivating breakfast room. A sunny media room to the left of the foyer provides built-in space for an entertainment system. The master bedroom contains a third fireplace and another gigantic bay window. Its adjoining bath is divided into His and Hers dressing areas and closets and centers around a relaxing whirlpool spa. Guests are easily accommodated in a full suite with its own living room and bath on the second floor. Three other bedrooms and a lounge share a balcony overlook to the living room below.


Full Specs & Features


Dimension

Depth : 82' 4"

Height : 38'

Width : 107' 1"

Area

First Floor: 3425 sq/ft

Second Floor: 2501 sq/ft

* Total Square Footage typically only includes conditioned space and does not include garages, porches, bonus rooms, or decks.

Roof

Primary Pitch : 12:12

Roof Framing : Truss

Exterior Wall Framing

Exterior Wall Finish : Stone

Framing : Wood - 2x6

Bedroom Features

Fireplace

Formal Dining Room

Formal Living Room / Parlor

Split Bedrooms

Additional Room Features

Family Room Keeping Room

Media Room

Outdoor Spaces

Covered Front Porch

Covered Rear Porch

What's Included In This Plan Set


All plans are drawn at ¼” scale or larger and include :

  • Foundation Plan: Drawn to 1/4" scale, this page shows all necessary notations and dimensions including support columns, walls and excavated and unexcavated areas.
  • Exterior Elevations: A blueprint picture of all four sides showing exterior materials and measurements.
  • Floor Plan(s): Detailed plans, drawn to 1/4" scale for each level showing room dimensions, wall partitions, windows, etc. as well as the location of electrical outlets and switches.
  • Cross Section: A vertical cutaway view of the house from roof to foundation showing details of framing, construction, flooring and roofing.
  • Interior Elevations: Detailed drawings of kitchen cabinet elevations and other elements as required.
