PLAN 472-274
This plan can be customized
Tell us about your desired changes so we can prepare an estimate for the design service. Click the button to submit your request for pricing, or call 1-800-447-0027 for assistance.Plan Description
Open, bright, and breezy: this plan is perfectly modern. The combined living and dining room opens via French doors (six sets!) to the spacious front porch and back patio. The kitchen offers a snack counter that overlooks the dining room for easy serving. The master suite includes a private bath with a window-side tub and separate shower, along with a walk-in closet and access to the patio. Bedroom 2 adjoins another full bathroom.
Full Specs & Features
Dimension
Depth : 49'
Height : 23'
Width : 59' 10"
Height : 23'
Width : 59' 10"
Area
First Floor: 1588 sq/ft
* Total Square Footage typically only includes conditioned space and does not include garages, porches, bonus rooms, or decks.
Roof
Primary Pitch : 12:12
Roof Framing : Conventional
Roof Type : Asphalt
Roof Framing : Conventional
Roof Type : Asphalt
Exterior Wall Framing
Exterior Wall Finish : Stone
Framing : Wood - 2x4
Framing : Wood - 2x4
Bedroom Features
Fireplace
Formal Dining Room
Formal Living Room / Parlor
Walk In Closet
Formal Dining Room
Formal Living Room / Parlor
Walk In Closet
Kitchen Features
Kitchenette Wet Bar
Walk In Pantry Cabinet Pantry
Walk In Pantry Cabinet Pantry
Garage Features
Detached Garage
Outdoor Spaces
Courtyard
Covered Front Porch
Covered Front Porch
Rooms
Bedroom 2:
223 sq/ft width 16' 4" x depth 13' 8"
Dining Room:
204 sq/ft width 10' 7" x depth 19' 4"
Living Room:
357 sq/ft width 18' 6" x depth 19' 4"
Master Bedroom:
209 sq/ft width 15' 4" x depth 13' 8"
What's Included In This Plan Set
- ELECTRICAL SCHEMATIC
- EXTERIOR ELEVATIONS
- CABINET ELEVATIONS
- CEILING FRAMING
- ROOF FRAMING
- FOUNDATION OF CHOICE AS AVAILABLE (SLAB, CRAWLSPACE OR BASEMENT) APPROPRIATE FOUNDATION DETAIL SHEET
- BUILDING CROSS SECTION IF MULTISTORY
- ALSO 4 PAGE FHA DESCRIPTION OF MATERIALS FORM (NOT A MATERIALS LIST OF QUANTITIES)
- GENERIC WALL SECTIONS
-
Note: Reproducible and CAD files are not available if building in Texas, Oklahoma, New Mexico, or Louisiana. Architect must update and stamp all plans being sent to these states.
Questions? Call 1-800-447-0027
Plan Set
| PDF Set : $995.00 |
PDF plan sets are best for fast electronic delivery and inexpensive local printing. |
Foundation
| Slab: $0.00 |
Ideal for level lot, single layer concrete poured directly on grade. |
| Crawlspace: $150.00 |
Ideal for semi-sloped or level lot, home can be built off of grade, typically 18” - 48”. |
| Basement: $300.00 |
Ideal for level lot, lower level of home partially or fully underground. |
Framing
| Wood 2x4: $0.00 |
Wood 2x4 |
Additional Options
| Right-Reading Reverse : $200.00 |
Choose this option to reverse your plans and to have the text and dimensions readable. |
| Additional Construction Sets : $40.00 |
Additional hard copies of the plan (can be ordered at the time of purchase and within 90 days of the purchase date). |
| Audio Video Design : $100.00 |
Receive an overlay sheet with suggested placement of audio and video components. |
| Construction Guide : $39.00 |
Educate yourself about basic building ideas with these four detailed diagrams that discuss electrical, plumbing, mechanical, and structural topics. |
| Lighting Design : $100.00 |
Receive an overlay sheet with suggested placement of lighting fixtures. |
*Alternate Foundations may take time to prepare.
*Options with a fee may take time to prepare. Please call to confirm.
Unless you buy an “unlimited” plan
set or a multi-use license you may only build one home from a set of plans. Please
call to verify if you intend to build more than once. Plan licenses are
non-transferable and cannot be resold.
Other Plans By this Designer
Browse Similar Plans
Recently Viewed House Plans
